The Precision 7740 is a 17.3‑inch “mobile workstation” — i.e. a laptop built for professional workloads requiring high compute, graphics, memory, and storage capabilities. It’s aimed at users doing heavy‑duty tasks like CAD/3D design, video editing, VFX, scientific computing, data analysis, machine learning, and other resource‑intensive workflows.
Because of its size, hardware and build, it’s more like a “portable desktop” than a light everyday notebook: powerful, expandable and versatile, but relatively heavy and oriented toward serious professional use.
High‑performance CPUs — supports 9th‑gen Intel Core series (i5 / i7 / i9) and Intel Xeon processors, giving flexibility depending on workload.
Large memory capacity — up to 128 GB DDR4 RAM (ECC or non‑ECC, depending on config) via four SODIMM slots, allowing serious multitasking, large data sets, 3D models, etc.
Professional-grade graphics — optional discrete GPUs: from AMD Radeon Pro to NVIDIA Quadro RTX (e.g. RTX 3000 / 4000 / 5000), suitable for 3D rendering, CAD, GPU‑accelerated compute, video editing, VR/AI workloads.
Flexible storage options — supports multiple drives: combination of M.2 PCIe NVMe SSDs and 2.5" SATA HDD/SSD, giving plenty of capacity (SSD for speed + HDD for large storage) depending on setup.
Large, high‑quality display choices — 17.3″ screen with multiple panel options: from FHD (1920×1080 IPS) to UHD (3840×2160 IGZO), with good color gamut (100% sRGB or 100% Adobe RGB depending on panel) — ideal for design, video work, color‑sensitive tasks.
Excellent connectivity & expandability — generous ports: multiple USB-A, 2× Thunderbolt 3 (USB‑C), HDMI, Mini DisplayPort, Ethernet, SD card reader, smart‑card reader (optional), and more — handy for multi‑monitor setups, external drives, peripherals.
Workstation-level certifications — many configurations come with ISV certification (for software used in engineering, architecture, 3D/VFX, scientific work), meaning better reliability and compatibility for professional applications.
Security & manageability — supports enterprise/security features: TPM 2.0, optional Smart Card reader, fingerprint reader or FIPS‑compliant authentication, plus support for remote management (with compatible CPU + vPro) — good for enterprise / business use.
Cooling & build for heavy workloads — designed with cooling and sustained performance in mind, to handle long rendering, compute, or simulation tasks without overheating or throttling.
Here’s a summary of what you can get (depending on configuration) with Precision 7740.
| Component | Specification / Options |
|---|---|
| Display | 17.3″ diagonal — options: • HD+ (1366×768) TN, anti‑glare, LED-backlight • FHD (1920×1080) UltraSharp IPS, 100% sRGB • UHD (3840×2160) IGZO, 100% Adobe RGB |
| Processors (CPU) | Intel Xeon E‑2276M / E‑2286M (6‑8 cores), or 9th‑gen Intel Core i5 / i7 / i9 (4‑8 cores) |
| Chipset | Intel Mobile CM246 |
| Memory (RAM) | Up to 128 GB DDR4 SDRAM (ECC or Non‑ECC), 4 SODIMM slots, 2666 MHz (some configs 3200 MHz) |
| Graphics (GPU) | Integrated: Intel UHD Graphics 630 (or P630) Discrete (various configs): • AMD Radeon Pro WX 3200 (4 GB GDDR5) • AMD Radeon Pro WX 7130 (8 GB GDDR5) • NVIDIA Quadro RTX 3000 (6 GB GDDR6) • NVIDIA Quadro RTX 4000 (8 GB GDDR6) • NVIDIA Quadro RTX 5000 (16 GB GDDR6) |
| Storage Options | Multiple drive support: • M.2 PCIe SSD (2280) — 256 GB / 512 GB / 1 TB / 2 TB (Class 40 or 50; some SED SSDs) • 2.5″ SATA HDD: 500 GB / 1 TB (7200 RPM), up to 2 TB (5400 RPM) Allows combinations of SSD + HDD for speed + capacity. |
| Ports & Connectivity | 4 × USB 3.1 Gen 1 (with PowerShare) 2 × Thunderbolt 3 (Type‑C) 1 × HDMI 2.0 1 × Mini DisplayPort 1.4 1 × SD/SDHC/SDXC card reader 1 × RJ‑45 Ethernet Headphone / microphone jack Optional smart‑card or contactless smart‑card reader / fingerprint reader (depending on config) |
| Wireless / Networking | Options include: Wi-Fi (802.11ac, Wi-Fi 6 possible depending on module), Bluetooth 4.2 or 5.0; optional WWAN/LTE depending on config. |
| Operating Systems supported | Windows 10 Pro / Windows 10 Pro for Workstations / Windows 10 Home (64‑bit) / Ubuntu 18.04 LTS / Red Hat (certain versions) — depending on build. |
| Battery (typical) | 6‑cell Li‑Ion Polymer battery, 97 Whr (ExpressCharge capable) — though as a workstation, heavy workloads will drain battery fast; usually used plugged in. |
| Form factor / Build / Portability | 17.3″ chassis, robust build (professional materials), weight around ~3.08 kg (varies with config) — heavy by laptop standards, but reasonable for a workstation. |
| Security & Manageability | Supports enterprise‑class security features: TPM 2.0, optional Smart Card / contactless smart‑card, Fingerprint reader / FIPS options, support for remote management via vPro (on compatible CPUs), plus enterprise software management tools from Dell (e.g. Client Command Suite). |
| Certification | Many builds are ISV‑certified, meaning compatibility and reliability with professional software (CAD, DCC, engineering tools, etc.) |
